Flex Pipe, Iveco, D2S+, Ø=77.1 / L=224, SS
D2S+ Round Double Interlocked Profile
Leakage Rate: 9.0 L min-1dm-2 @0.30bar
Flexibility/Force: 60-250 N (±23mm from mid position)
Axial Extension: > = 30% (> = 90mm)
Maximum Torsion: 5˚ (@ compressed length of 300mm)
Dinex nº | 28270 |
EAN | 5700760021912 |
Longitud [mm] | 240.00 |
Diámetro exterior [mm] | 80.50 |
Diámetro interior [mm] | 77.10 |
Altura [mm] | 80.00 |
Ancho [mm] | 80.00 |
Peso neto [kg] | 0.70 |
Compressed length | 224 |
Extended Length | 291 |
Installation Length | 258 |
Material | Stainless Steel |
